Schlumberger RF6 Radial Drilling and Tapping Machine

Radial Drilling & Tapping Machine made by Schlumberger (France) in excellent working condition. The model of the machine is RF 6 and the Drilling Capacity is 50 mm. Due to its unique design the machine is suitable for small sized jobs as well as large sized jobs and the setting time is comparatively very less as compared to a normal design radial drill machine. The machine can do Drilling as well as Tapping operations. The technical details are as follows -

Make - Schlumberger (France)

Model - RF 6

Drilling Capacity - 50 mm

Spindle Diameter - 90 mm

Spindle Speeds - 35 rpm to 1800 rpm

Spindle Taper - MT 4

Spindle Feed Rate - 0.06 mm/min to 0.60 mm/min

Spindle Feed Travel - 355 mm

Max. Height between Spindle to Table Top - 945 mm

Max. Height between Spindle to Base Clamping Table - 1370 mm

Min. Distance between Spindle Center to Pillar - 125 mm

Max. Distance between Spindle Center to Pillar - 900 mm

Table Size - 1000 mm x 710 mm

Base Clamping Table Size (Back-Side) - 920 mm x 640 mm

Vertical Clamping Table Size - 800 mm x 790 mm

Head Rotation - 360 degree

Clamping Type - Automatic ; Hydraulic

- With Automatic Tapping Feature.

- Complete with Vice, Tool Holder, & Coolant Pump.

- Machine is in excellent working condition.
